Can Depalletizer

DPL-1000

The DPL-1000 Depalletizer automates bulk can handling by staging pallets, removing slip sheets, and sweeping each layer onto the conveyor. An integrated chain lift system elevates cans layer by layer, while a single filer indexes them into controlled flow for the canning line. Operators manage all functions from a touchscreen PLC, with adjustable sweep, hoist, and filer speeds plus customizable alerts and can size settings. Built-in safety systems—including light curtains, automatic doors, and component safety locks—protect both staff and equipment during operation.

  • Dimensions & Weight

    • L: 256" (6503 mm)

    • W: 119" (3023 mm)

    • H: 200" (5080 mm)

    • Weight: ~4500 lbs (2042 kg)

    ​​

    Performance

    • Speed: Up to 1400 CPM

    ​​

    Utilities

    • Power:

      • 208–240 V, 3 Phase

      • ​380/460V (upcharge)​

    • Air: 8 CFM @ 110 PSI

  • Workflow & Automation

    • Double Pallet Staging Area – holds two pallets for continuous can feed without reloading.

    • Automated Pallet Infeed & Discharge – seamless changeover between staged and empty pallets.

    • Automatic Empty Pallet Stacking – reduces manual handling.

    • Slip Sheet Handling – pneumatic slip sheet removal with flat rack accumulation for easy return to the can maker.

    • Top Frame Removal – simply cut pallet straps; the system handles the picture frame.

    • Full Top Layer Sweep – transfers cans smoothly onto the conveyor.

    • Integrated Chain Lift System – automatically elevates cans to the next layer.

    • Side-Driven Sweep Arm with Locking Hardware – keeps cans aligned and clean during operation.

    • Mass Conveyor Discharge with Single Filer – combines bulk outfeed with controlled can flow.

    • Can Pack Control During Sweeping – prevents tipping during layer transfer.


    Safety Systems

    • Automatic Safety Doors – enclose the pallet during operation for added protection.

    • Ground-Level Mesh Fence with Light Curtains – detects obstructions at pallet infeed/discharge.

    • Platform Safety Fence with Light Curtains – monitors platform area and stops operation if blocked.

    • Safety Locks on Components – prevent accidental drops in the event of power failure.


    Performance & Reliability

    • Superior Motors and Gearboxes – equipped with food-grade bearings for durability.

    • Three VFDs for Speed Flexibility:

      • Hoist VFD – controls pallet rise/descend.

      • Sweep VFD – controls can sweep into the single filer.

      • Single Filer VFD – controls can feed speed into the track.


    Controls & Options

    • PLC with Large Touchscreen HMI – intuitive operator interface.

    • Optional Remote Access – monitor or adjust from phone or tablet.

    • Multiple Configurations & Heights – customizable to fit packaging line layouts.

  • ​Codi warranties our products against defects in design and workmanship for up to 12 months after shipment or 1,000,000 cans produced, whichever comes first.

    ​

    Third-party components are covered under their manufacturer’s warranties, and we’ll support you in making any claims.



    During the warranty period we will repair or replacement of defective parts (wear parts excluded).
