Counterpressure Filler + Seamer
CCL-45CE
Due to demand from European breweries for our counterpressure filler, we developed a version that is fully compliant with the EU's CE standards. It also happens to be a great solution for those who require an enclosed canning line.
Like the CCL-45 it can package products with high carbonation levels (up to 4.0 Vols) and it accommodates high incoming liquid temperatures (~50F). Built from stainless steel with true clean-in-place capability, it’s engineered to workhorse for your beverage packaging business while providing quality filling and seaming.
It is a proven machine, trusted by hundreds of craft producers around the globe—including breweries, coffee roasters, kombucha makers, and more. Those who know, rely on the Codi CCL-45.
Product Videos
Dimensions & Weight
-
L: 84" (2134 mm)
-
W: 34" (864 mm)
-
H: 70" (1778 mm)
-
Weight: ~1845 lbs (837kg)
Performance
-
Speed: Up to 55 CPM under ideal conditions
Utilities
-
Power: 208–240 V, 3 Phase
-
Air: 11 CFM @ 110 PSI
-
CO₂: 60 PSI (16 oz: 50 lbs/110 cs; 12 oz: 35 lbs/100 cs)
Beverage Parameters
-
Temperature: 28 – 52 °F (–2 – 11 °C)
-
Carbonation: 0 – 4 vol CO₂ (0 – 8 g/L)
-
Product Quality
-
Industry-leading lowest dissolved oxygen pickup in micro-canning.
-
Counter Pressure technology enables canning across a wider range of temperatures and carbonation levels.
-
Built-in buffer tank pressurizes liquid with CO₂ before filling, keeping carbonation in solution.
-
Post-fill to seam foam management with controlled pressure release.
-
Continuous CO₂ monitoring throughout the fill process.
Cleaning & Sanitation (TACT-Compatible)-
Temperature – Brewery hose rated for high pressure and up to 180°F (82°C), with Tri-Clover sanitary fittings.
-
Action / Flow Rate – Cleaning solution is recirculated for high flow rates while conserving resources.
-
Chemicals – 304 stainless steel construction withstands caustic cleaning agents.
-
Time – PLC-controlled cycles for precise cleaning durations.
Control & Safety-
HMI provides centralized control over fill rates, pressure, and snift cycles.
-
Audible and visual alerts notify operators if the system is compromised.
-
Integrated sensors monitor stacked lids and lid drop for uninterrupted operation.
Consistency & Reliability-
Cam-driven seaming delivers consistent seals every time.
-
Engineered for repeatable performance and easy operator oversight.
-
Filling & Carbonation Control
-
Counterpressure filling ensures precise fills without exposing product to the atmosphere.
-
Pressurizes liquid before injection, allowing filling across wider temperature and carbonation ranges without overfilling.
-
304 stainless steel counterpressure fill heads seal the can, purge oxygen with CO₂, then fill under pressure to retain carbonation and reduce waste.
CIP
-
Fully CIP (Clean-in-Place) capable for quick, thorough sanitation between runs.
-
High-temperature, high-pressure rated components allow longer contact time with caustic cleaners.
-
Closed-loop cleaning system saves resources by recirculating liquid.
Seaming & Consistency
-
Seamer is synchronized with the feed screw to perform critical operations at the exact same timing every run.
-
Mechanical seaming delivers consistent seams and simplifies troubleshooting or adjustments.
Flexibility & Integration
-
Change parts allow quick conversion for standard, sleek, and slim cans of any volume.
-
Easily integrates with existing conveyors, twist rinses, and other equipment.
Monitoring & Control
-
Centralized control of purge cycles, tank pressure, pump rate, fill rate, settle time, and snift cycles.
Durability and Service
-
Crafted with 304 stainless steel and precision-machined in-house for long-term durability.
-
In-house service technicians available whenever you need assistance.
-
Codi warranties our products against defects in design and workmanship for up to 12 months after shipment or 1,000,000 cans produced, whichever comes first.
Third-party components are covered under their manufacturer’s warranties, and we’ll support you in making any claims.
During the warranty period we will repair or replacement of defective parts (wear parts excluded).
